Finally...an affordable On-Site Vibratory Screener.
Site Screener vibratory hopper-type screeners are available in three (3) sizes to match your capacity requirements. Each model can quickly screen and separate the various types of materials your projects might require. Be it topsoil, loam, sand, gravel, drainage rock, septic stone, road base, or clean fill, the Site Screener can match your demand with ease. From the raw materials generated on-site by site clearing, trenching, foundation/basement excavation, site reclamation, stump removal, septic systems, paving, utility repair, road repair, demolition...just put the right model for your loader to work today and you'll discover why our customers say... "The Site Screener's uses are limited only by your imagination."
The Site Screener is
Efficient - as easy to use as loading a truck - fast 30 second cycle time - always a one man job.
Versatile - 500 screen sizes currently available - accepts nearly all material - no-clog hopper.
Portable - can be pulled by 3/4 or 1 ton truck.
Profitable - low investment - high yield per hour - low operating costs = FAST PAYBACK
Built to Last - rugged beam construction, heavy plate steel, diesel powered, all hydraulic.
Three sizes of Site Screener are available.
XL45 6ft x 7ft 2-deck vibratory screener. Can be fed with any 2-3 cu.yd. Loader. Internal conveyor carries screened fine material to front side of machine. Oversized materials vibrate off back side of screen deck.
XL30 4ft x 7ft 2-deck vibratory screener. Can be fed with any 1-2 cu.yd. Loader. Internal conveyor carries screened fine material to front side of machine. Oversized materials vibrate off back side of screen deck.
XL20 4ft x 7ft 2-deck vibratory screener. Can be fed with any skid steer loader or landscape tractor. Internal conveyor carries screened fine material to front side of machine. Oversized materials vibrate off back side of screen deck.
Site Screener design features:
- screen deck vibration action design for optimal material separation
- economical John Deere diesel engine
- Operates up to 1-1/2 days on a single tank of fuel
- 30 minutes to change a screen (or less)
- can be towed by 3/4 or 1 ton truck
- setup time: approximately 5 minutes
- all models have hydraulic operated legs for leveling and stability
- Internal conveyors have belt sensor system with auto-shut down
- XL30 and XL45 screeners are mounted on integral trailers with tandem axles; trailer does not have to be removed to operate screener; XL20 has hydraulic lifting rear legs
- trailers have 300-400 pound tongue weight, pintle hitches, electric brakes, lights, breakaway switches
- 6 easy-grease points, all on one side
- an optional stacking conveyor can be used for the screened fine material or for the oversized material; reserve hydraulic power is bilt into the Site Screener to operate a stacker.
For pricing, contact our Sales office at 1-800-881-3318.
